Meet EPA Regulations with Low Cost Spill Containment for Multiple IBC Tanks
I N D O O R |
2-Tank Model (Indoor) | 3-Tank Model (Indoor) | 4-Tank Model (Indoor) | 5-Tank Model (Indoor) | |
Part# | 1125 | 1126 | 1127 | 1128 | |
Dims: | 186" x 62" x 8 ¾" (4724 mm x 1575 mm x 222 mm) |
248" X 62" X 8 ¾" (6299 mm x 1575 mm x 222 mm) |
279" x 62" x 8 ¾" (7087 mm x 1575 mm x 222 mm) |
310" x 62" x 8 ¾" (7874 mm x 1575 mm x 222 mm) |
|
Included Pallets: | 2 | 3 | 4 | 5 | |
Included Expansion Tanks: | 2 | 2 | 1 | 0 | |
Weight Capacity: 9,000 lbs. UDL per Pallet (4083 kg) |
|||||
Gallon Capacity: | 280 gal. (1060 L) | 355 gal. (1344 L) | 365 gal. (1382 L) | 375 gal. (1419 L) | |
Weight: | 310 lbs. (141 kg) | 435 lbs. (198 kg) | 531 lbs. (241 kg) | 625 lbs. (284 kg) | |
Required accessory: Part# 1118 - Assembly Kit (Includes hole saw, arbor and set of (2) Tightening Tools | |||||
Option for Indoor Models: Spill Pallet Only - Part# 9630 | |||||
O U T D O O R |
2-Tank Model (Outdoor) | 3-Tank Model (Outdoor) | 4-Tank Model (Outdoor) | 5-Tank Model (Outdoor) | |
Part# | 1165 | 1166 | 1167 | 1168 | |
Dims: | 126" x 93" x 79" (3201 mmx 2363 mm x 2007 mm) |
188" x 93" x 79" (4776 mm x 2363 mm x 2007 mm) |
250" x 93" x 79" (6350 mm x 2363 mm x 2007 mm) |
312" x 62" x 79" (7925 mm x 1575 mm x 2007 mm) |
|
Included Pallets: | 2 | 3 | 4 | 5 | |
Included Expansion Tanks: | 2 | 2 | 1 | 0 | |
Weight Capacity: 9,000 lbs. UDL per Pallet (4083 kg) |
|||||
Gallon Capacity: | 280 gal. (1060 L) | 355 gal. (1344 L) | 365 gal. (1382 L) | 375 gal. (1419 L) | |
Weight: | 881 lbs. (400 kg) | 1258 lbs. (571 kg) | 1603 lbs. (728 kg) | 1948 lbs. (884 kg) | |
Required accessory: Part# 1118 - Assembly Kit (Includes hole saw, arbor and set of (2) Tightening Tools | |||||
Option for Outdoor Model: Extender Kit - Part# 9658 |
Options for Indoor & Outdoor Model Spill Pallets:Part# 1117 - 2" Bulkhead Fittings (Set of 2) Part# 1124 - Expansion Tank Only, 61" x 31" x 12½" (1550 mm x 788 mm x 318 mm), Capacity: 65 gallons, 30 lbs. |
|||||
Product Instructions | |||||
View this product in our e-catalog |
