Capture Hazardous Spills From Railroad Tanker Cars
Track Pans with Grates, No Covers | Track Pan Covers Only |
Part# 9566 - Center Track Pan with Grates | Part# 9580 - Cover for Center Track Pan |
Dimensions: 53½" x 53½" x 6" (1359 mm x 1359 mm x 153 mm) |
Dimensions: 55" x 52 1/2" (1397 mm x 1333 mm) |
Weight:112 lbs. (51 kg) | Weight: 24 lbs. (11 kg) |
Containment Capacity: 18 gallons (69 L)* | Containment Capacity: - |
Includes: 2 bulkhead fittings, 4 gaskets and 2 grates | |
Part# 9576 - Side Track Pan with Grates | Part# 9581 - Cover for Side Track Pan |
Dimensions: 53½" x 27½" x 6" (1359 mm x 699 mm x 153 mm) |
Dimensions: 55" x 28 1/4" (1397 mm x 717 mm) |
Weight:58 lbs. (26 kg) | Weight: 11 lbs. (5 kg) |
Containment Capacity: 19 gallons (72 L)* | Containment Capacity: - |
Includes: 1 bulkhead fitting, 2 gaskets and 1 grate | Includes: - |
*Because of wheel flange clearance the effective height of the Center Pans is shorter than the effective height of the Side Pans causing the Center Pans to have less capacity than the Side Pans. | |
Complete Railroad Spill Containment Systems | |
9-Foot Railroad Spill Containment Systems: | |
Part# 9595 - Two (2) Center Pans, four (4) Side Pans. No covers | |
Part# 9596 - Two (2) Center Pans with Covers, four (4) Side Pans with Covers | |
40-Foot Railroad Spill Containment Systems: | |
Part# 9589 - Nine (9) Center Pans, eighteen (18) Side Pans. No covers | |
Part# 9590 - Nine (9) Center Pans with Covers, eighteen (18) Side Pans with Covers | |
60-Foot Railroad Spill Containment Systems: | |
Part# 9592 - Fourteen (14) Center Pans, twenty-eight (28) Side Pans. No covers | |
Part# 9593 - Fourteen (14) Center Pans with Covers, twenty-eight (28) Side Pans with Covers | |
View / Download catalog page |
Options | |
Part# 9584 - Rebar Fasteners with Protective Caps (20-pack) | |
Part# 9559 - 3" dia. Bulkhead Fitting (for below grade piping) | |
Part# 9571 - Grate Only for Center Pan (Left) Part# 9571 - Grate Only for Center Pan (Right) |
|
Part# 9573 - Grate Only for Side Pan |
