Ultra-Safety Cabinet Bladder Systems

Ultra-Safety Cabinet Bladder Systems


Out Of Sight, Should Not Be Out Of Mind..

Código: Ultra-Safety Cabinet Bladder Systems. Categorías: , , .
Descripción

Fire-rated drum safety cabinets were designed many years ago. Their primary goal was to protect the contents from direct flame and heat - spill control was not a consideration. Ultra-Safety Cabinet Bladder Systems allow convenient and economical retrofitting of all drum safety cabinets on the market. You can easily comply with fire and spill containment regulations!

  • Simply raise existing drum cabinets 8" from the floor, slide the Safety Cabinet Bladder System in place, and lower the cabinet on top of the structural steel frame. Heavy duty, inner steel framework will keep the cabinet stable, even in a fire.
  • Ultra-Safety Cabinet Bladder Systems are designed to retrofit all vertical drum storage cabinets on the market. (See support frame dimensions below for more information)
  • V1 Model (for 1-drum cabinets) and V2 Model (for 2-drum cabinets) are the only low-profile spill containment devices specifically for safety cabinets.
  • Bring your vertical drum storage cabinets into compliance with EPA 40 CFR 264.175 and Uniform Fire Code Article 7901.8.5 for spill containment of flammable and combustible liquids.
  • Significant leaks or spills unfurl the hidden containment bladder to provide complete spill containment. Small spills are captured inside the polyethylene sump.
  • Low profile design firmly positions drum cabinets only 6 1/4" off the plant floor, thereby allowing wastes to be poured into drum-top funnels at a convenient height. The potential for splashes into the eyes or face is significantly reduces as compared to taller containment devices.
  • Drum corrosion leaks can occur anytime, day or night. Significant leaks flow over the cabinet door sill and into the polyethylene containment bladder will automatically unfurl as the sump fills up.

Ultra-Safety Cabinet Bladder Systems
Ultra-Safety Cabinet Bladder System V1 1-Drum Model Ultra-Safety Cabinet Bladder System V2 2-Drum Model
Part# 2420 Part# 2421
Overall Dimensions:
37¾" x 37¾" x 6¼"
(959 mm x 959 mm x 159 mm)
Overall Dimensions:
63½" x 37¾" x 6¼"
(1,600 mm x 978 mm x 159 mm)
Support Frame Dimensions:
Outside - 34½" x 34½" (876mm x 876mm)
Inside - 28½" x 28½"
(724mm x 724mm)
Support Frame Dimensions:
Outside - 59½" x 34½"
(1511mm x 876mm)
Inside - 53½" x 28½"
(1359mm x 724mm)
Weight: 57 lbs. (26 kg) Weight: 85 lbs. (39 kg)
Load Capacity: 1500 lbs. (681 kg) Load Capacity: 3000 lbs. (1,361 kg)
Containment Capacity: 93 gallons (352 L) Containment Capacity: 111 gallons (420 L)
See this product in our e-catalog
